Models Covered:

- Ranger XP 800 (2010 - 2012)
- Ranger XP 800 EPS (2012 - 2012)
- Ranger HD 800 (2010 - 2012)
- Ranger Crew 800 (2010 - 2014)
- Ranger Crew 800 EPS (2011 - 2013)
- Ranger 4x4 800 (2013 - 2014)
- Ranger 4x4 800 EPS (2013 - 2014)

*** This manual also INCLUDES international model coverage ***

Every Clymer contains hundreds of original photographs and illustrations developed from a complete disassembly and assembly of the Motorcycle. This, in addition to extensive research, allows Clymer to achieve an un-matched level of detail, accuracy & clarity.

The step-by-step instructions and two column text with large print are user friendly, bold figure numbers make it easy to quickly match instructions with illustrations and photos. Thumb tabbed chapters, numbered table of contents and extensive index make it possible to locate the desired section quickly.

Contents:

• General Information
• Troubleshooting
• Lubrication, Maintenance & Tune-Up
• Engine Top End
• Engine Lower End
• Clutch and Drive Belt System
• Transmission & Shift Mechanism
• Air-Fuel and Exhaust System (Carbureted Models)
• Air-Fuel System (Fuel-Injected Models)
• Electrical System
• Cooling System
• Wheels, Tires & Hubs
• Front Suspension, Steering and Front Drive System
• Rear Suspension and Rear Drive System
• Brakes
• Frame & Body
• Index
• Color Wiring Diagrams
