 General Motors 6T70 / 6T75 Transaxle ATSG Rebuild Manual
General Motors 6T70 / 6T75 Transaxle ATSG Rebuild Manual

General Motors 6T70 / 6T75 Transaxle ATSG Rebuild Manual

  • Hassle Free Returns - NO RMA's!
  • No Restocking Fees
  • Over 173,000 Satisfied Customers
  • 30 Day Money Back Guarantee*
    (*Restrictions Apply. See Return Policy)
General Motors 6T70 / 6T75 Transaxle ATSG Rebuild Manual
Click to enlarge image(s)
FREE Economy Shipping & Handling in USA For Orders Over $200!
The Hydra-matic 6T70/75 (6 Speed) is a fully automatic, six speed, front wheel drive, electronically controlled transmission that features clutch to clutch shifting. It is also all-wheel drive capable. It was first introduced in the 2007 model year in several different models. It consists primarily of a four element torque converter, three planetary gear sets, five clutch packs, one mechanical one-way clutch and a hydraulic pressurization and control system. Three planetary gear sets provide the six forward gear ratios and reverse. Changing gear ratios is fully automatic and is accomplished through the use of a Transmission Control Module (TCM), that is located within the transmission. The TCM receives and monitors various electronic sensor inputs, and uses this information to shift the transmission at the optimum time. The TCM commands shift solenoids and variable bleed Clutch Pressure Control (CPC) solenoids within the transmission to control shift timing. The TCM controls shift feel through the CPC solenoids. The TCM also controls the apply and release of the torque converter clutch which allows the engine to deliver the maximum fuel efficiency without sacrificing vehicle performance. This ATSG 6T70/75 Technical Manual contains the procedures necessary to diagnose, overhaul and/or repair the 6T70/75 (6 Speed) transmission from General Motors.

Contents:
  • General Description and Vehicle Application Chart
  • Component Location and Identification
  • Component Application Chart
  • Shift Quadrants
  • Identification Tag Information, Fluid Requirements
  • Torque Converter Clutch Operation
  • Electronic Component Operation
  • Solenoid Application Chart
  • Solenoid Description and Operation
  • Internal Mode Switch Operation
  • Input Speed Sensor
  • Output Speed Sensor
  • Typical Wire Schematic
  • Diagnostic Trouble Code Description
  • Connectors and Terminal Identification
  • Low One-Way "Diode Style" Clutch Description
  • Hydralic Passage Identification
  • Checkball Location and Function
  • Transmission Disassembly
  • Component Rebuild Section
  • Transmission Final Assembly
  • Low One-Way Freewheel Direction
  • Thrust Bearing and Thrust Washer Identification
  • Torque Specifcation
  • Special Tools
  • Line Pressure Check
  • Fluid Level Check and Fluid Requirement
Specifications
Publisher: ATSG
Softcover: Approx. 120 pages
Dimensions: 8.5 x 11.0 x 0.2 inches
Submit a Review...
