Ford 6R140W Torqshift 6 Transmission Rebuild Manual
- Hassle Free Returns - NO RMA's!
- No Restocking Fees
- Over 173,000 Satisfied Customers
- 30 Day Money Back Guarantee*
(*Restrictions Apply. See Return Policy)
|
 |
| Click to enlarge image(s) |
- Covers the Ford 6R140W Torqshift 6 transmission found in 2011 and up Ford Super-Duty trucks.
- Includes transmission assembly, dis-assembly, diagnosis, troubleshooting, electronic controls, and operation.
At the start of production for the 2011 model year Ford Motor Company introduced a newly designed full time six speed 6R140W transmission also known as the Torqshift® 6, for the F250 to F550 Super Duty truck models equipped with the 6.2L Gas Flex Fuel engine or the 6.7 Turbo Diesel engine. It is available in both 2WD and 4WD configurations and can be Power Take-Off capable. The 6R140W assembled weight is 350 Lbs. and is of the Lepelletier geartrain design consisting of a Simpson planetary gearset, a Ravigneaux gear set, two holding clutches, three drive clutches, a one-way clutch and a torque converter clutch. TCC can be commanded on from first to sixth gear. The 6R140W is electronically controlled by seven pwm solenoids and uses a Transmission Control Module (TCM) in diesel powered applications or a Powertrain Control Module (PCM) for gasoline powered applications. When the TCM/PCM detects a fault, Failure Mode Effect Management (FMEM) will be initiated and the transmission will enter fifth and reverse gear limp mode. The transmission system is also capable of Tow Haul Mode which will provide all six speeds at higher shift points and also has manual shift capability.
Contents:
- General Description and Transmission Application
- Component Application
- Shift Quadrant Information
- Transmission Identification
- Transmission Fluid Level Drain and Fill Procedure
- Line Pressure Testing and Specifications
- Solenoid Body Identification and Strategy
- Solenoid Application and Identification
- Adaptive Drive Cycle and Solenoid Body Strategy Download
- Solenoid Function and Operation
- Typical Wire Schematic - Gasoline Engines
- Transmission & PCM Connector Terminal Identification - Gasoline Engines
- Typical Wire Schematic - Diesel Engines
- Transmission & PCM Connector Terminal Identification - Diesel Engines
- Transmission Ranger Sensor and Output and Turbine Speed Sensor Description
- Transmission Fluid Temperature Sensor and Four Wheel Drive Description
- Diagnostic Trouble Codes
- Transmission Disassembly
- Component Rebuild Section
- Transmission Assembly
- Main Control Valve Body - Disassemble
- Main Control Valve Body - Assemble
- Transmission Assembly Continued
- Case Passage Identification
- Torque Specifications
- Specialty Tools
| Specifications | |
| Publisher: | ATSG |
| Softcover: | Approx. 112 pages |
| Dimensions: | 8.5 x 11.0 x 0.3 inches |
