Chrysler 62TE 6-Speed Transaxle ATSG Rebuild Manual CD-ROM
- Hassle Free Returns - NO RMA's!
- No Restocking Fees
- Over 173,000 Satisfied Customers
- 30 Day Money Back Guarantee*
(*Restrictions Apply. See Return Policy)
![Chrysler 62TE 6-Speed Transaxle ATSG Rebuild Manual CD-ROM Chrysler 62TE 6-Speed Transaxle ATSG Rebuild Manual CD-ROM](/account/images/image.img?color=006600&text=000000&accent=cccc66&compliment=003300&navigation=ffffff&heading=003300&title=cccc33&logo=006600&link=000000&picture.image.url=%2Ffiles%2F573683%2Fuploaded%2F83-62TE-CD.png&picture.width.max=298&picture.image.mask.apply=false&stage.width.max=746&cache=1725655800570) |
Click to enlarge image(s)
|
FREE Economy Shipping & Handling in USA For Orders Over $200!
This manual provides techniques required to perform transmission repairs, overhaul, diagnosis & testing.
The new 62TE transaxle by the Chrysler Group is fitted behind a 3.5L V6 engine in the Avenger, Sebring and Sebring Convertibles (JS Body), the 4.0L V6 engines in Pacifica (CS Body) and the 3.3L, 3.8L, 4.0L Caravan and Grand Caravan vehicles. It has 6 forward speeds with a 7th forward gear used in a specific downshift sequence known as the “4th prime". Fourth prime ratio is 1.573:1 which is a ratio between third gear (2.284:1) and fourth gear (1:452:1). Refer to the Component Application Chart. Fourth prime is used for a smoother highway speed kickdown from sixth gear and to provide a better ratio for climbing grades under certain conditions. This transaxle has another technical first for Chrysler in that this transaxle introduces the "double-swap" shifts on the 2-3, 3-2 and 4-2 shifts. This occurs when two components are turned off while two different components are turned on. This clutch to clutch syncronization takes place within 40-70 milliseconds, producing a very smooth shift. To avoid a "Double-Swap" shift on a 6-4 downshift, the transaxle shifts into "4th Prime" instead of 4th gear, which requires only the OD clutch to be turned off and simultaneous application of the UD clutch. A freewheel device (sprag) is used to assist in smoother shifts with its nonsynchronous application and release properties. The sprag holds in first, third and fourth assisting in smoother 1-2, 2-1, 4-5 and 5-4 shifts.
Manual Contents:
|
- General Description & Vehicle Application Chart
- Component Application and ID
- Component Application Chart
- ID Tag, Fluid Requirement, Fluid Fill Info
- External Electronic Component Operation
- Typical Wire Schematic
- Case Connector Terminal ID & Function
- Control Module Locations
- Control Module Connector Information
- Internal Electronic Component Operation
- Solenoid, Switch & Component Application Chart
- Transaxle Range Switch/Sensor Operation
- Checking Line Pressure & Specifications
- Diagnostic Trouble Codes
|
- Checkball Locations and Air Testing
- Oil Passage Identification
- EMCC (TCC) Converter Operation
- Transaxle Disassembly
- Component Rebuild
- Final Transaxle Assembly
- Set Compounder Section End-Play
- Thrust Bearing & Washer ID & Location
- Torque & Clearance Specifications
- Special Tools
- Non-Removable Checkballs, Pressure Taps Eliminated
|
Publisher:
|
Automatic Transmission Service Group (ATSG)
|
Softcover:
|
Approx. 120 pages
|
Dimesnions:
|
8.5 x 11.0 x 0.3 inches
|
